• Touch protection IP 20 – when fuse link is in test mode IP rating is maintained
• Parking position of switch operating cover even with fuse-links inserted
• Modular system of cover – cover for cable termination area can be extended as required
• Varieties of cable termination: screw, bolt, clamp strap, extendable for V-terminal – optional
• Padlocking and sealing of switch door cover – optional
• Indicating switch for switch door position – optional
• Installation on to DIN rails in accordance with EN 60 715 – optional
• Safe on load connection/disconnection in accordance with IEC 60947-3
APPLICATIONS
• Power distribution and Motor protection
• Photovoltaic application: Protection on lines of String inverters rated at 800Vac
STANDARDS
• IEC/EN 60 947-3 For NH-fuse links size 1 and size 2 in accordance with IEC/EN 60 269, VDE 0636
